2-GPCS-133SD - Semi-Auto Carton Sealer

This is a top of the line semi automatic case sealing machine used for uniformed sized cartons and will seal both top and bottom of boxes with packaging tape at the same time. It has been designed to suit medium to heavy duty uniform carton sealing applications with changeover of the machine tape made easy with a simple changeover feature. This involves pulling away the takeaway convey from the drive belts to pull out the tape head and reload quickly and easily. The video features shows the GPCS-133SD working with a ViaJet Thermal Inkjet printer

2-GPCS-C26U - Side Drive Carton Sealer

The latest additional to the Get Packed range of carton sealers. The C26U uniform carton sealer is a side drive model that has a 50mm wide belt that can move cartons at a rate of 20m per minute - pulling the cartons through the dual head (top and bottom) taping mechanisms. It will accomodate cartons as little as 150mm x 150mm x 120mm (height) up to 500mm x 500mm (height) x any length. Other features include adjustable leg heights to match conveyors and legs on castors for easy relocation.

Packmasta 100 - Side Drive Carton Sealer

The Packmasta 100 Side Drive Carton Sealer and applies tape to the top and bottom of boxes using two side belts while the tape head applies the tape. It will tape box dimensions of - L (no limit) W (120-480mm) H (120-480mm), will suit tape sized from 48-60mm (machine tape) and has a sealing speed of 30 cartons/minute.

Packmasta 100

Packmasta 100

GPEXC range of Carton Sealers

The GPEXC range of Carton Sealers feature the 103TB (top and bottom drive). The 103SD (side drive) and the 103SD-SS (which is a side drive stainless steel carton sealer). The side drive model (103SD) is ideal for use when the carton is too full or if the carton has extreme dimenions. Also available are tape heads exclusively for the GPEXC range. Please click on the images below for more specific information on each carton sealer.

Top and Bottom Drive 103TB

Top and Bottom Drive 103TB

Side Drive 103SD

Side Drive 103SD

Side Drive 103SD-SS

To find out more information on each of the GPEXC range of carton sealers please click on the images below.

GPXT Range of Carton Sealers

The GPXT 36 Carton Sealer is a side belt driven sealer that uses tape on both top and bottom of the carton. It is easily adjustable for both height and width for different sized cartons.Maximum seal dimensions are 500mm x 500mm.
The GPXT37 is top belt driven and is also easily adjustable. Maximum seal dimensions are 500mm x 500mm.
Please click on the shopping cart below for more information.

Top Belt Drive

GPXT36

GPXT37

GPEC Range of Carton Sealers

The GPEC range of carton sealers has Semi Automatic as well as Automatic carton sealers. The Semi Auto carton sealers are built for dependable performance and easy operation featuring both a side belt drive which is recommended for low profile, small and lightweight cartons, as well as a Top and Bottom Belt drive carton sealer that is designed for cartons with a higher and wider profile. Our 705A Carton sealer is an automatic random carton sealer with both a top and bottom belt drive. Our largest of this series is the 801 which is an Automatic Case Erector and bottom sealer which is particularly suited for longer or higher cartons. Click on the images below for more information on each.

To find out more information on each of the GPEC range of carton sealers please click on the images below.

Semi Automatic Carton Sealer
2-GPCT50

This height and width adjustable carton sealer uses a simple mechanical operation sealing cartons with tape on the top and the bottom with the tape head being easily removed. Being a side belt driven design it is ideal for low profile, small and lightweight boxes with speeds of up to 2500 cartons per hour depending on carton sizes.

Low Profile Carton Sealer
S8-4P

This Siat model low profile carton sealer is a manually adjustable side belt model. It features patented taping heads (for 50mm tape width) and can do both top and bottom or top or bottom carton sealing. It can average 15 cartons per minute.

Automatic Carton Sealers

The Siat Automatic Case Erector features bottom gluing units that spread hot melt glues onto the bottom flaps of the boxes and motorised storage for 150 boxes and a production capacity of 6/8 boxes per minute depending on the box size. Its procedure involves folding and sealing the bottom flaps with hot melt glue spread while boxes are passing through motorization. At the end of the cycle one presser will press the four glued flaps for optimizing their conjunction before filling.
The Siat Automatic Hot Melt Carton Sealer has either top or top and bottom gluing unit spreading the glue on the top (or top & bottom) carton flap while boxes are passing through the machine. Once glued, boxes are kept pressed to allow a proper adhesion. Production capacity is within 10/18 boxes per minute depending on box size.
For more information on either of these carton sealers please either click on the brochures below or click on the shopping cart.

Automatic Case Erector

Automatic Case Erector

Automatic Hot Melt Carton sealer

Automatic Hot Melt Carton sealer
